Product details
MT0808-NA1
- 8x HDMI input, 8x HDMI output
- 4K@60Hz 4:4:4, HDR10, HLG, DolbyVision and full 3D
- Analogue & digital audio de-embedding from output
- LCD panel, IR, RS-232, TCP/IP and Web GUI for control
- EDID management
- HDCP 2.2 compliant
|
-
The MT0808-NA1 is an 8x8 HDMI Matrix Switcher with Audio Embedding and Extraction, it is compatible with high dynamic range (HDR) formats and is HDCP 2.2 compliant. It supports 4K/UHD video @ 60Hz with 4:4:4 chroma sampling, as well as HDMI data rates up to 18Gbps. It routes eight Hi-Def sources to any eight HDTV displays, along with multichannel digital audio formats such as Dolby® True HD and DTS-HD® Master Audio™. Each source can be routed to any display using the Push Buttons, IR Remote, RS232, TCP/IP, GUI and Web GUI.
Features:
- Supports 4K@60Hz 4:4:4, HDR and full 3D
- HDCP 2.2/HDCP1.x and DVI compliant
- Supports L/R stereo audio embedding into the HDMI Input 1-2
- Supports audio extracting from the HDMI Output 1-8
- Multiple switching mode: IR Remote, Push Buttons, RS232, TCP/IP, GUI and Web GUI
- Advanced EDID management for rapid integration of sources and displays
- With rack mounting ears for easy installation
-
Signal
HDMI Compliance
HDMI 2.0
HDCP Compliance
HDCP 2.2 and HDCP 1.x
Video Resolutions
18Gbps (4K@60Hz 4:4:4 8bit)
HDMI Cable Distance
1.5 meters for 4K@60Hz 4:4:4
RS232 Baud Rate
57600
IR Carrier Frequency
30-55KHz at 5 volts
Chroma Subsampling
4:4:4, 4:2:2, 4:2:0
Color Space
RGB, YCbCr4:4:4, YCbCr4:2:2, YCbCr4:2:0
Color depth
1080p 48bit, 4K 24bit
Audio Formats
Up to PCM 8 channel, Dolby Digital TrueHD and DTS-HD Master Audio
I/O Connections
HDMI Inputs
8x HDMI Type A Female
HDMI Outputs
8 x HDMI Type A Female
IR In
9x 3.5mm Stereo Earphone Jack
IR Out
8x 3.5mm Stereo Earphone Jack
Audio Inputs
2x 3.5mm Stereo Earphone Jack
Audio Outputs
8x RCA Jack (SPDIF), 8x 3.5mm Stereo Earphone Jack
TCP/IP
1x 8P8C Port (Shielded RJ45 Female), 100BaseT
RS232
1x DB9 Port Female
Temperature
Operating
32°F to 104°F (0°C to 40°C)
Storage
-4°F to 140°F (-20°C to 60°C)
Humidity (RH)
20% to 90%, non-condensing
Power
Consumption
27W (Max. 11.8V/2.286A)
Idle Consumption
1.8W (11.9V/0.152A)
Supply
Input: 100-240V AC, 50/60Hz,
Output: 12V/3A DC (US/EU standards, CE/FCC/UL certified)
ESD Protection
Air-gap discharge
±8kV
Contact discharge
±4kV
Dimensions & Weight
Dimensions
439mm x 226mm x 44mm (1-RU) , without feet
Weight
3.2Kg
-
