Product details

MT0402-A40

  • 4x HDMI input, 2x HDMI output
  • 4K@60Hz 4:2:0, full 3D
  • Analogue & digital audio de-embedding from output
  • Push button, IR, RS-232 for control
  • EDID management
  • HDCP 1.4 compliant

MT0402-A40

  • 4x HDMI input, 2x HDMI output
  • 4K@60Hz 4:2:0, full 3D
  • Analogue & digital audio de-embedding from output
  • Push button, IR, RS-232 for control
  • EDID management
  • HDCP 1.4 compliant
  • The MT0402-A40 4×4 Matrix with audio extractors for HDMI routes two Hi-Def sources to any four  HDTV displays, supporting 1080p Full HD up to 4K plus all 3D formats, along with multichannel digital audio formats such as Dolby® True HD and DTS-HD® Master Audio™. Each source can be routed to any display using the front-panel push buttons, IR remote control, and RS-232 interface.

    Swiss 1:1 quality 2024 Top Swiss Made Replica Watches UK at affordable prices have everything that one expects to find.

    Swiss made Omega Fake Watches UK Shop for both men and women at affordable prices can be found from this website.


    Features:


    • Supports resolutions up to 1080p@60HZ,48-bit deep color, 4k@30HZ
    • Allows any source to be displayed on multiple displays at the same time
    • Allows any HDMI display to view any HDMI source at any time
    • Dolby TrueHD and DTS-HD master audio pass through HDMI output
    • Advanced EDID management for rapid integration of sources and displays
    • Multiple switching mode, push-in button, IR remote control, RS-232 control
    • Easy installation with mounting ears
    • Full 3D pass through.
    • HDCP compliant


  • Bandwidth

    2.97Gbps per color

    Video Input Connectors

    4x HDMI Type A, 19-pin, female

    Video Output Connectors

    2x HDMI Type A, 19-pin, female

    Audio Output Connectors

    2x RCA(SPDIF), 2 xL/R

    RS232 Serial port

    DB-9, female

    IR input ports

    3x3.5mm stereo jack

    IR output ports

    4x3.5mm stereo jack

    Rack-Mountable

    rack ears included

    Dimensions(Lx Wx D)

    260mm x 105mm x 39mm, w/o feet

    Shipping Weight

    1.0KG

    Operating Temperature

    32°F to 104°F (0°C to 40°C)

    Storage Temperature

    -4°F to 140°F (-20°C to 60°C)

    Power Supply

    5V/1A DC
